CPUIntel® Socket LGA1200 for 11th Gen Intel® Core™ Processors & 10th Gen Intel® Core™, Pentium® Gold and Celeron® ProcessorsSupports Intel® 14 nm CPUSupports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**ChipsetZ590MemoriaMemory Channels: 4DDR4 (Dual channel)Max Memory Size: 128GBDDR4 5133(OC)/5000(OC)/4800(OC)/4700(OC)/4600(OC)/4500(OC)/4400(OC) /4266(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory*Dual Channel Memory ArchitectureSupports Intel® Extreme Memory Profile (XMP)OptiMem II* 10th Gen Intel® Core™ i7/i9 processors support 2933/2800/2666/2400/2133 natively, others will run at the maximum transfer rate of DDR4 2666MHz.* 11th Gen Intel® processors support 3200/2933/2800/2666/2400/2133 natively. * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and memory frequency support depends on the CPU types.Gráficos1 x DisplayPort 1.4**1 x HDMI™ 2.0***1 x DisplayPort 1.4**1 x HDMITM 2.0**** Graphics specifications may vary between CPU types.** Intel® 11th & 10th processors support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz. Please refer to www.intel.com for any updates.*** Only Intel® 11th processors, support HDMI™ 2.0 with max. resolution of 4K@60Hz, others would only support HDMI™ 1.4 with max. resolution of 4K@30Hz .Please refer to www.intel.com for any update.**** VGA resolution support depends on processors' or graphic cards' resolution. Ranuras de expansión1 x PCIe 4.0/3.0 x16 + 1 x PCIe 3.0 x16 (max. x4)Intel® 11th & 10th Gen Processors1 x PCIe 4.0/3.0 x16 slot*- Intel® 11th processors support PCIe 4.0 x16- Intel®10th processors support PCIe 3.0 x16Intel® Z590 Chipset1 x PCIe 3.0 x16 slot (supports x4 mode)2 x PCIe 3.0 x1 slots* Supports PCIe bandwidth bifurcation for RAID on CPU function. * Enable RST PCIe Storage Remapping for PCH attached PCIe slots to activate Intel® Optane Memory.AlmacenamientoSupports 3 x M.2 slots and 6 x SATA 6Gb/s portsTotal supports 3 x M.2 slots and 6 x SATA 6Gb/s portsIntel®11th Gen ProcessorsM.2_1 slot (Key M), type 2242/2260/2280/22110- Only Intel® 11th processors support PCIe 4.0 x4 mode, this slot will be disabled for other CPUsIntel® Z590 ChipsetM.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)***M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes)****6 x SATA 6Gb/s ports* Raid function for PCIe mode SSD in Intel® Rapid Storage Technology is available with either 1. Intel® SSDs installed in both CPU-attached and PCH-attached slots, or 2. any other 3rd party SSDs installed in PCH-attached slots.** To enable Intel® Optane™ Memory (Hybrid Storage device), it must be installed in PCH-attached slots with Intel® Rapid Storage Technology.*** M.2_2 shares bandwidth with SATA6G_2. When M.2_2 runs SATA mode, SATA6G_2 will be disabled. **** M.2_3 shares bandwidth with SATA6G_56. When M.2_3 is occupied, SATA6G_56 will be disabled.Ethernet1 x Intel® 2.5Gb EthernetWireless y BluetoothWi-Fi 62x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)Supports 2.4/5GHz frequency bandBluetooth v5.2USBRear USB:Total 7 ports1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®)2 x USB 3.2 Gen 2 ports (2 x Type-A)2 x USB 3.2 Gen 1 ports (2 x Type-A)2 x USB 2.0 ports (2 x Type-A) Front USB:Total 7 ports1 x USB 3.2 Gen 1 connector (suppports USB Type-C®)1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 portsAudioRealtek ALC S1200A 7.1 Surround Sound High Definition Audio CODEC*- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking- Supports up to 24-Bit/192 kHz playbackAudio Features- Audio Shielding- Rear optical S/PDIF out port- Premium Japanese audio capacitors- Dedicated audio PCB layers - Audio coverPuertos E/S traseros1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®)2 x USB 3.2 Gen 2 ports (2 x Type-A)2 x USB 3.2 Gen 1 ports (2 x Type-A)2 x USB 2.0 ports (2 x Type-A)1 x DisplayPort1 x HDMI™ port1 x ASUS Wi-Fi Module1 x Intel® I225-V 2.5Gb Ethernet port5 x Audio jacks1 x Optical S/PDIF out port 1 x PS/2 Keyboard/Mouse combo portPuertos internos1 x Thunderbolt 4 headerFan and Cooling related1 x 4-pin CPU Fan header1 x 4-pin CPU OPT Fan header1 x 4-pin AIO Pump header3 x 4-pin Chassis Fan headersPower related1 x 24-pin Main Power connector1 x 8-pin +12V Power connector1 x 4-pin +12V Power connectorStorage related3 x M.2 slots (Key M)6 x SATA 6Gb/s portsUSB1 x USB 3.2 Gen 1 connector (supports USB Type-C®)1 x USB 3.2 Gen 1 headers supports additional 2 USB 3.2 Gen 1 ports2 x USB 2.0 headers support additional 4 USB 2.0 portsMiscellaneous2 x AURA Addressable Gen 2 headers2 x AURA RGB headers1 x Clear CMOS header1 x COM Port header1 x Front Panel Audio header (AAFP)1 x 20-3 pin System Panel header with Chassis intrude function 1 x Thunderbolt™ headerFunciones especiales de ASUSASUS TUF PROTECTION- DIGI+ VRM (- Digital power design with DrMOS)- Enhanced DRAM Overcurrent Protection- TUF LANGuard- Overvoltage ProtectionASUS Q-Design- M.2 Q-Latch- Q-DIMM- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])- Q-SlotASUS Thermal Solution- M.2 heatsink- VRM heatsink designASUS EZ DIY- ProCool- Pre-mounted I/O shield- SafeSlotAURA Sync- AURA RGB headers - Addressable Gen 2 RGB headersSoftwareASUS Exclusive SoftwareArmoury Crate- AURA Creator- AURA Sync- Two-Way AI Noise CancelationAI Suite 3- Performance And Power Saving UtilityTurboV EVOEPUDigi+ VRMFan Xpert 4- EZ updateTUF GAMING CPU-ZAI ChargerASUS Turbo LANDAEMON ToolsDTS Custom for GAMING HeadsetsMyASUSNorton Anti-virus software (Free Trial version)WinRARUEFI BIOSASUS EZ DIY- ASUS CrashFree BIOS 3- ASUS EZ Flash 3- ASUS UEFI BIOS EZ ModeBIOS192 (128+64) Mb Flash ROM, UEFI AMI BIOSManejabilidadWOL by PME, PXEAccesoriosCables2 x SATA 6Gb/s cablesMiscellaneous1 x ASUS Wi-Fi moving antenna2 x M.2 Rubber Packages1 x M.2 SSD screw package1 x TUF Gaming stickerInstallation Media1 x Support DVDDocumentation1 x TUF Certification card1 x User manualFactor de forma
