TARJETA MADRE ASUS PRIME B560-PLUS LGA 1200 /AURA SYNC/HDMI/DP/ATX

CPUIntel® Socket LGA1200 for 11th Gen Intel® Core™ processors & 10th Gen Intel® Core™, Pentium® Gold and Celeron® ProcessorsSupports Intel® 14nm CPUSupports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0** Refer to www.asus.com for CPU support list.** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.ChipsetIntel® B560 ChipsetMemory4 x DIMM, Max. 128GB,DDR4 4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200(OC)/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered memory*Dual channel memory architectureSupports Intel® Extreme Memory Profile (XMP)ASUS OptiMem* 11th Gen Intel® Core™ processors support 2933/2800/2666/2400/2133 natively.* 10th Gen Intel® Core™ i7/i9 processors support 2933/2800/2666/2400/2133 MHz natively, others will run at the maximum transfer rate of DDR4 2666MHz.Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and memory frequency support depends on the CPU types.Graphics1 x DP1.2**1 x HDMITM 1.4/2.0***1 x D-Sub*Graphics specifications may vary between CPU types.** For Intel® 11th & 10th processors, support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz. Please refer to www.intel.com for any update.***Only Intel® 11th Core™ processors support HDMI™ 2.0 with max. resolution of 4K@60Hz, others will only support HDMI™ 1.4 with max. resolution of 4K@30Hz. Please refer to www.intel.com for any updates.Expansion SlotsIntel® 11th &10th Gen Processors1 x PCIe 4.0/3.0 x16 slot*- Intel® 11th Core™ processors support PCIe 4.0 x16- Intel®10th processors support PCIe 3.0 x16Intel® B560 Chipset1 x PCIe 3.0 x16 slot (supports x4 mode)*2 x PCIe 3.0 x1 slots*Enable RST PCIe Storage Remapping for PCH attached PCIe slots to activate Intel® Optane Memory.StorageTotal supports 2 x M.2 slots and 6 x SATA 6Gb/s portsIntel® 11th Gen Processors- M.2_1 slot (Key M) type 2242/2260/2280/22110 (supports PCIE 4.0 x 4 )- Only Intel® 11th Core™ processors support PCIe 4.0 x4 mode, this slot will be disabled for other CPUsIntel® B560 Chipset- M.2_2 slot (Key M) type 2242/2260/2280/22110 (supports PCIE 3.0 x 4 & SATA mode mode)- 6 x SATA 6Gb/s portsWhen a device in SATA mode is installed on the M.2_2 socket, SATA6G_2 port cannot be used.When an Intel® SSD is connected to a CPU-attached slot, only pass-through Single Volume mode in Intel® Rapid Storage Technology will be available.Ethernet"Intel® I219-VASUS LANGuard"USBRear USB (Total 7 ports)2 x USB 3.2 Gen 2 ports (2 x Type-A)1x USB 3.2 Gen 1 port (1 x USB Type-C®)4 x USB 2.0 portsFront USB (Total 6 ports)1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports2 x USB 2.0 headers support additional 4 USB 2.0 portsAudioRealtek ALC897 7.1-Channel High Definition Audio CODEC*- Jack-detection, Multi-streaming, Front Panel Jack-retasking- Supports up to 24-Bit/192kHz playbackAudio Features- Audio Shielding- Premium Japanese audio capacitors- Dedicated audio PCB layers*A chassis with an HD audio module in the front panel is required to support 7.1-channel audio output.Back I/O Ports1 x DP port1 x HDMI port1 x D-Sub port3 x Audio jacks1 x PS/2 Keyboard/Mouse combo port1 x Intel® I219-V 1Gb Ethernet port4 x USB 2.0 ports (4 x Type-A)2 x USB 3.2 Gen 2 ports (2 x Type-A)1x USB 3.2 Gen 1 port (1 x USB Type-C®)Internal I/O ConnectorsFan and cooling-related1 x 4-pin CPU Fan header3 x 4-pin Chassis Fan headersPower related1 x 24-pin Main Power connector1 x 8-pin +12V Power connectorStorage related2 x M.2 slots (Key M)6 x SATA 6Gb/s portsUSB1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports2 x USB 2.0 headers support additional 4 USB 2.0 portsMiscellaneous2 x AURA Addressable Gen 2 headers2 x AURA RGB headers1 x Clear CMOS jumper1 x COM Port header1 x Front Panel Audio header (AAFP)1 x S/PDIF out header1 x 20-3pin System Panel header with Chassis intrude function1 x SPI TPM header (14-1 pin)1 x Thunderbolt 4 headerSpecial FeaturesASUS 5X PROTECTION III- ASUS DIGI+VRM- ASUS LANGuard- ASUS Overvoltage Protection- ASUS SafeSlot Core+- ASUS Stainless-Steel Back I/OASUS Q-Design:- ASUS Q-DIMM- ASUS Q-SlotASUS Thermal Solution- Flexible M.2 heatsink- VRM heatsink designASUS EZ DIY- Box HeadersAURA SYNC- AURA RGB headers- Addressable Gen 2 RGB headersSoftware FeaturesASUS Exclusive Software:Armoury Crate- AURA Creator-AURA SyncAI Suite 3-Performance And Power Saving UtilityTurbo EVODigi+ VRMEPUFan Xpert 2+- EZ updateASUS CPU-ZDAEMON ToolsNorton Anti-virus software(Free Trial for 60 days)WinRARUEFI BIOSASUS EZ DIY- ASUS CrashFree BIOS 3- ASUS EZ Flash 3- ASUS UEFI BIOS EZ ModeBIOS128 Mb Flash ROM, UEFI AMI BIOSManageabilityWOL by PME, PXEAccessoriesCables2 x SATA 6Gb/s cablesMiscellaneous1 x M.2 Rubber Package1 x IO Shield1 x M.2 SSD screw package1 x M.2 Key E screw packageInstallation Media1 x Supporting DVDDocumentation1 x User's manualOperating SystemWindows® 10 - 64 bitForm FactorATX Form Factor12.0 inch x 9.2 inch (30.5 cm x 23.4cm
