MOTHERBOARD ASROCK AM1B-M AM1

ModeloAM1B-MCPU- Supports AMD Socket AM1 Athlon/Sempron APUSocketAM1Chipset Memoria- 2 x DDR3 DIMM Slots- Supports DDR3 1600/1333/1066 non-ECC, un-buffered memory- Max. capacity of system memory: 32GB*Tarjeta Gráfica- Integrated AMD Radeon™ R3 Series Graphics in A-series / E-series APU- DirectX 11.1, Pixel Shader 5.0- Max. shared memory 4GB- Supports D-Sub with max. resolution up to 2048x1536 @ 60HzAudio- 5.1 CH HD Audio (Realtek ALC662 Audio Codec)- Supports Surge Protection (ASRock Full Spike Protection)LAN- PCIE x1 Gigabit LAN 10/100/1000 Mb/s- Realtek RTL8111GR- Supports Wake-On-WAN- Supports Wake-On-LAN- Supports Lightning/ESD Protection (ASRock Full Spike Protection)- Supports LAN Cable Detection- Supports Energy Efficient Ethernet 802.3az- Supports PXEPuertos de expansión   - 1 x PCI Express 2.0 x16 Slot (PCIE1 @ x4 mode)- 1 x PCI Express 2.0 x1 SlotSoporte Multi-GPU Almacenamiento- 2 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot PlugUSB- 4 x USB 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection))- 2 x USB 3.0 Ports (Supports ESD Protection (ASRock Full Spike Protection))Conectores I/OInternos  - 1 x Print Port Header- 1 x COM Port Header- 1 x Chassis Intrusion Header- 1 x TPM Header- 1 x CPU Fan Connector (4-pin)- 1 x Chassis Fan Connector (4-pin)- 1 x Power Fan Connector (3-pin)- 1 x 24 pin ATX Power Connector- 1 x 4 pin 12V Power Connector- 1 x Front Panel Audio Connector- 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection))Puertos posteriores- 1 x PS/2 Mouse/Keyboard Port- 1 x D-Sub Port- 4 x USB 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection))- 2 x USB 3.0 Ports (Supports ESD Protection (ASRock Full Spike Protection))- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)- HD Audio Jacks: Line in / Front Speaker / MicrophoneFactor de forma- Micro ATX Form Factor
