TARJETA MADRE ASUS TUF Z270 MARK 2 DDR4 HDMI/DPORT 1151

CPUIntel® Socket 1151 for 7th/6th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors Supports Intel® 14 nm CPUSupports Intel® Turbo Boost Technology 2.0 * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.* Refer to www.asus.com for CPU support listChipsetIntel® Z270Memoria4 x DIMM, Max. 64GB, DDR4 3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666(O.C.)/2400(O.C.)/2133 MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP)* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).* The maximum memory frequency supported varies by processor.GráficaIntegrated Graphics Processor- Intel® HD Graphics support Multi-VGA output support : HDMI/DVI-D ports - Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz- Supports DVI-D with max. resolution 1920 x 1200 @ 60 HzMaximum shared memory of 1024 MBSoporte Multi-GPUSupports NVIDIA® 2-Way SLI™ Technology Supports AMD CrossFireX™ TechnologyPuertos de Expansión2 x PCIe 3.0/2.0 x16 (x16 or dual x8) 1 x PCIe 3.0/2.0 x16 (x2 mode) 3 x PCIe 3.0/2.0 x1Almacenamiento1 x M.2 Socket 3, , with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & X4 PCIE mode)1 x M.2 Socket 3, , with M Key, type 2242/2260/2280 storage devices support (PCIE mode only)6 x SATA 6Gb/s port(s), graySupport Raid 0, 1, 5, 10Supports Intel® Smart Response Technology*2Intel® Optane™ Memory Ready *3LANIntel® I219V, 1 x Gigabit LAN Controller(s)ASUS Turbo LAN UtilityAudioRealtek® ALC887 8-Channel High Definition Audio CODEC - Supports : Jack-detection, Front Panel Jack-retaskingAudio Feature :- LED-illuminated design - Brighten up your build with the gorgeous illuminated audio trace path.- Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference- Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals- Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelityPuertos USBASMedia® USB 3.1 controller : 2 x USB 3.1 Gen 2 port(s) (2 at back panel, +teal blue, Type-A)Intel® Z270 Chipset : 8 x USB 3.1 Gen 1 port(s) (4 at back panel, +blue, 4 at mid-board)Intel® Z270 Chipset : 6 x USB 2.0 port(s) (2 at back panel, , 4 at mid-board)Capacidades EspecialesTUF Features:TUF ENGINE! Power Design :- 4 +2 Digital Phase Power Design- TUF Components (Choke, Cap. & MOSFET; certified by military-standard)Ultimate COOL! Thermal Solution :- Thermal Radar Core+Safe & Stable! Guardian Angel :- TUF ESD Guards 2- TUF LANGuardASUS Exclusive Features :- MemOK!- AI Suite 3- Ai Charger - ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface File Transfer- Cloud GO!- File TransferASUS EZ DIY :- ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode- Multi-language BIOSASUS Q-Design :- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)- ASUS Q-Slot- ASUS Q-DIMM - ASUS Q-ConnectorOverclocking Protection :- ASUS C.P.R.(CPU Parameter Recall)Turbo APPM.2 Onboard(The latest transfer technologies with up to 32Gb/s data transfer speeds)Puertos posteriores I/O1 x PS/2 keyboard/mouse combo port(s)1 x DVI-D1 x HDMI1 x LAN (RJ45) port(s)2 x USB 3.1 Gen 2 (teal blue)4 x USB 3.1 Gen 1 (blue) 2 x USB 2.0 1 x Optical S/PDIF out5 x Audio jack(s)Internal I/O2 x USB 3.1 Gen 1 connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s) (19-pin)2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & X4 PCIE mode)1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (PCIE mode only)6 x SATA 6Gb/s connector(s)1 x CPU Fan connector(s) (1 x 4 -pin)2 x Chassis Fan connector(s) (2 x 4 -pin)1 x S/PDIF out header(s)1 x 24-pin EATX Power connector(s)1 x 8-pin ATX 12V Power connector(s)1 x Front panel audio connector(s) (AAFP)1 x MemOK! button(s)1 x Clear CMOS jumper(s)1 x 14-1 pin TPM connector1 x System panel connector1 x COM port header1 x AIO PUMP HeaderAccesoriosUser's manual2 x SATA 6Gb/s cable(s)1 x M.2 Screw Package1 x SLI HB BRIDGE(2-WAY-M)1 x Q-connector(s) (1 in 1) 1 x TUF Certification card(s)1 x TUF 5 Year Warranty manual(s) (by region)1 x TUF Inside sticker(s)(white)1 x SCDBIOS128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0, ACPI 6.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen and ASUS DRAM SPD (Serial Presence Detect) memory informationSistema operativoWindows® 10 64-bitWindows® 8.1 64-bit *4Windows® 7 32-bit *4Windows® 7 64-bit *4Form FactorATX Form Factor 12.0 inch x 9.2 inch ( 30.5 cm x 23.4 cm )Nota1.When a device in SATA mode is installed on the M.2_1 socket, SATA_1 port cannot 1.Cuando un dispositivo en modo SATA es instalado en un socket M.2_1, el puerto SATA_1 no podrá ser usado.2. Estas funciones trabajarán dependiendo del CPU instalado.3.La tecnología Intel® Optane solo es soportada al usar procesadores Intel® de 7a generación. Antes de usar modulos de memoria Intel® Optane™, asegurate de actualizar los controladores de tu tarjeta madre y BIOS a la última versión del sitio de soporte de ASUS.4.Windows® 8.1 64-bit y Windows® 7 32/64-bit solo son soportados cuando se usa procesadores Intel® de 6a generación.be used.2.These functions will work depending on the CPU installed.3.Intel® Optane Technology is only supported when using 7th Generation Intel® processors. Before using Intel® Optane memory modules, ensure that you have updated your motherboard drivers and BIOS to the latest version from ASUS support website.4.Windows® 8.1 64-bit and Windows® 7 32/64-bit are only supported when using 6th Generation Intel® ProcessorsTodas las especificaciones están sujetas a cambios sin previo aviso. Por favor consulte a su proveedor para ofertas exactas. Los productos pueden no estar disponibles en todos los mercados.El color de la PCB y las versiones del software incluido están sujetas a cambio sin previo aviso.La marca y los nombres de los productos mencionados son marcas registradas por sus respectivas compañías.
