MOTHERBOARD ECS INTEL NM70-I2

CPUº Onboard Intel® Celeron 847/807/1037U processorsº Solid Capacitor for CPU sideCHIPSETº Intel® NM70 Express ChipsetGRAPHICSº Support Intel® HD Graphics 2000º Supports DirectX® 10.1º Supports HDMI 1.4a & Premium Audioº Supports Full HD 1080P Blu-ray / HD-DVD PlaybackMEMORYº Dual-channel DDR3 Memory architecture º Supports DDR3 1333/1066 non-ECC, Un-buffered SDRAM Memoryº 2 X 240-pin DDR3 DIMM socket º Support up to 16 GB*EXPANSION SLOTº 1 X PCI Express X16 Gen 2.0 slot(s)Storageº Support by IntelNM70 Express Chipset    • 1 X Serial ATAIII 6Gb/s    • 3 X Serial ATAII 3Gb/sAudioº VIA 1705‧VIA® VT1705 6-channel High Definition audio CODEC‧Compliant with HD audio specification for a whole new immersive surround sound experience‧3 DACs and 2 ADCs with High-performance ADCs with 100dB SNR, DACs with 100dB SNR‧Low Power Consumption‧Capability for “full rate” BluRay / DVD / HD DVD support.LANº Realtek 8111E Gigabit Fast Ethernet Controllerº (Realtek 8105E 10/100Mbps Fast Ethernet Controller optional)USBº Support by NM70 Express Chipset    • 8 X USB2.0 port(s) Up to 480 Mb/s      Back Panel 4 port(s)      Onboard 4 port(s)REAR PANEL I/Oº 1 X PS/2 Keyboard & PS/2 mouse connectorsº 1 X Serial port (COM)º 1 X Audio port (Line Out/Line In/Mic In) º 1 X HDMI port(s)º 1 X DVI-I port(s) (optional)º 1 X D-Sub (VGA) port(s)º 4 X USB2.0 port(s)CONNECTORS & HEADERSº 1 X 24-pin ATX Power Supply connectorº 1 X 3-pin CPU_FAN connectorº 1 X 3-pin SYS_FAN connectorº 1 X Front Panel switch/LED headerº 1 X Front panel audio headerº 1 X Onboard Buzzerº 2 X USB 2.0 header    • Support additional 4 USB portsº 1 X S/PDIF out headerº 1 X SATA III 6Gb/s connector(s)º 3 X SATA II 3Gb/s connector(s)º 1 X CLR_CMOS headerº 1 X Serial port header (COM) º 1 X Parallel port header (LPT)º 1 X ME_UNLOCK headerº 1 X Chassis intrusion headerº 1 X LVDS connector (optional)º 1 X LDC headerSYSTEM BIOSº AMI BIOS with 32 MB SPI Flash ROMº Over-Clockingº Multi-Language BIOSFORM FACTORº Mini ITX Form Factorº 170mm X 170mmOS Supportº Windows XP 64-bitº Windows 7 32-bitº Windows 7 64-bitº Windows 8 64-bitCertificationsº CE/FCC Certificationº ErP/EuP Certification º WHQL Certification º WHCK CertificationBundled Softwareº ECS Intelligent EZ Utility : eBLU, eDLU, eSFº Free Bundle: Norton Internet Security ,CyberLink PowerDVD, CyberLink PowerDirector 9, Muzee with trial version
