TARJETA MADRE ASUS ROG STRIX Z590-A GAMING WIFI /LGA 1200/DDR4/WI-FI 6

CPUIntel® Socket LGA1200 for 11th Gen Intel® Core™ Processors & 10th Gen Intel® Core™, Pentium® Gold and Celeron® ProcessorsSupports Intel® 14 nm CPUSupports Intel® 14 nm CPUSupports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0*** Refer to www.asus.com for CPU support list.** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.ChipsetZ590MemoriaDDR4 5333(OC)5133(OC)/5000(OC)/4800(OC)/4600(OC)/4500(OC)/4400(OC)/4267(OC)/4133(OC)/4000(OC)/3866(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory*Dual Channel Memory ArchitectureSupports Intel® Extreme Memory Profile (XMP)OptiMem II* 10th Gen Intel® Core™ i7/i9 processors support 2933/2800/2666/2400/2133 natively, others will run at the maximum transfer rate of DDR4 2666MHz.* 11th Gen Intel® processors support 3200/2933/2800/2666/2400/2133 natively.* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).Gráficos1 x DP1.4*** Graphics specifications may vary between CPU types.** Only Intel® 11th processors support DisplayPort 1.4 with max. resolution of 5120 x 2880 @60Hz, others will only support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz. Please refer to www.intel.com for any updates*** Only Intel® 11th processors support HDMI™ 2.0 with max. resolution of 4K@60Hz, others will only support HDMI™ 1.4 with max. resolution of 4K@30Hz .Please refer to www.intel.com for any updates.Puertos de Expansión3 x PCIe 4.0/3.0 x16 (x16, x8/x4/x4)Intel® 11th &10th Gen Processors3 x PCIe 4.0/3.0 x16 slot(s)*- Intel® 11th processors support PCIe 4.0 x16 or x8/x4/x4 mode(s)- Intel® 10th processors support PCIe 3.0 x16 or x8/x4/x4 mode(s)Intel® Z590 Chipset1 x PCIe 3.0 x4 slot* Supports PCIe bandwidth bifurcation for RAID on CPU function.AlmacenamientoIntel®11th Gen ProcessorsM.2_1 slot (Key M), type 2242/2260/2280/22110- Only Intel® 11th Core™ processors support PCIe 4.0 x4 mode, this slot will be disabled for other CPUs.Intel® Z590 ChipsetM.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)*M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)**6 x SATA 6Gb/s portsRaid function in Intel® Rapid Storage Technology is available with either 1. Intel® SSDs installed in both CPU-attached and PCH-attached slots, or 2. any other 3rd party SSDs installed in PCH-attached slots.To enable Intel® Optane™ Memory (Hybrid Storage device), it must be installed in PCH-attached slots with Intel® Rapid Storage Technology.*When M.2_2 is operating in SATA device, SATA6G_2 will be disabled.**When M.2_3 is operating in SATA device, SATA6G_6 will be disabled.LAN1 x Intel® 2.5Gb EthernetRedes InalámbricasWi-Fi 62x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) Supports 2.4/5GHz frequency bandBluetooth v5.2Puertos USBRear USB:Total 10 ports1 x USB 3.2 Gen 2x2 port(s) (1 x USB Type-C®)4 x USB 3.2 Gen 2 port (4 x Type-A)5 x USB 2.0 port(s) (4 x Type-A + 1 x USB Type-C®)Front USB:Total 7 ports1 x USB 3.2 Gen 1 connector(s) (support(s) USB Type-C®)1 x USB 3.2 Gen 1 header(s) support(s) additional 2 USB 3.2 Gen 1 ports2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 portsAudio"ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080- Impedance sense for front and rear headphone outputs- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input- Supports up to 32-Bit/384 kHz playback"Audio Features - SupremeFX Shielding Technology- ALC4080 + Savitech SV3H712 AMP- audio jacks- Rear audio USB Type-C® port- Premium Japanese audio capacitors- Audio cover Puertos E/S Traseros1 x USB 3.2 Gen 2x2 port(s) (1 x USB Type-C®)4 x USB 3.2 Gen 2 port(s) (4 x Type-A)5 x USB 2.0 port(s) (4 x Type-A, 1 x Audio USB Type-C®)1 x HDMI™ port1 x DisplayPort1 x ASUS Wi-Fi Module1 x Intel® I225-V 2.5Gb Ethernet5 x Audio jacks1 x BIOS FlashBack™ buttonPuertos InternosFan and Cooling related 1 x 4-pin CPU Fan header(s)1 x 4-pin CPU OPT Fan header(s)1 x 4-pin AIO Pump header(s)4 x 4-pin Chassis Fan header(s)1 x VRM heatsink Fan headerPower related 1 x 24-pin Main Power connector1 x 8-pin +12V Power connector1 x 4-pin +12V Power connectorStorage related 3 x M.2 slots (Key M)6 x SATA 6Gb/s portsUSB 1 x USB 3.2 Gen 1 connector (support(s) USB Type-C®)1 x USB 3.2 Gen 1 header(s) support(s) additional 2 USB 3.2 Gen 1 ports2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 portsMiscellaneous3 x AURA Addressable Gen 2 header(s)1 x AURA RGB header(s)1 x Clear CMOS header1 x CPU Over Voltage jumper1 x Front Panel Audio header (AAFP)1 x SPI TPM header (14-1pin)1 x 20-3 pin System Panel header with Chassis intrude function1 x Thermal Sensor header1 x Thunderbolt header1 x S/PDIF out headerCaracterísticas EspecialesExtreme Engine Digi+- 5K Black Metallic CapacitorsASUS Q-Design - M.2 Q-Latch- Q-DIMM- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])- Q-SlotASUS Thermal Solution- M.2 heatsink backplate- M.2 heatsinkASUS EZ DIY- BIOS FlashBack™ button- BIOS FlashBack™ LED- ProCool II- Pre-mounted I/O shield- SafeSlotAURA Sync- AURA RGB header(s)- Addressable Gen 2 RGB header(s)Características de SoftwareROG Exclusive Software- RAMCache III- ROG CPU-Z- GameFirst VI- Sonic Studio III + Sonic Studio Virtual Mixer- Sonic Radar III- DTS® Sound Unbound- Overwolf- Anti-virus softwareASUS Exclusive SoftwareArmoury Crate- AIDA64 Extreme (60 days free trial)- AURA Creator- AURA Sync- Two-Way AI Noise CancelationAI Suite 3- 5-Way Optimization with AI OverclockingTPUEPUDigi+ VRMFan Xpert 4Turbo app- EZ updateDAEMON ToolsMyAsusWinRARUEFI BIOSMemTest86AI Overclocking GuideASUS EZ DIY- ASUS CrashFree BIOS 3- ASUS EZ Flash 3- ASUS UEFI BIOS EZ ModeFlexKeyBIOS256 Mb Flash ROM, UEFI AMI BIOSManejabilidadWOL by PME, PXEAccesoriosCables1 x ROG audio USB Type-C® cable4 x SATA 6Gb/s cablesMiscellaneous1 x ASUS 2x2 Dual-Band Wi-Fi moving antennas1 x Cable ties pack1 x M.2 Q-Latch package2 x M.2 Rubber Packages1 x ROG key chain1 x ROG STRIX sticker1 x ROG STRIX thank you cardInstallation Media1 x Support DVDDocumentation1 x User manualFactor de formaATX30.5cm x 24.4cm
